Product overview

Rigid substrate for precision printing

PVC rigid printable film is a semi-rigid to rigid PVC substrate engineered for high-definition digital printing applications. The material features a smooth, dimensionally stable surface that accepts UV, eco-solvent, and screen printing technologies. Unlike flexible films, this rigid grade maintains its flatness during printing and subsequent handling, eliminating distortion and register shift. The surface is treated to promote ink adhesion without primer, while the white opaque base ensures excellent color vibrancy and contrast. Available in thicknesses from 0.30mm to 0.80mm, the film is suitable for signage, point-of-purchase displays, industrial labeling, and decorative panels.

Core advantages

Dimensional stability

Minimal thermal expansion and contraction. Maintains flatness during printing, lamination, and fabrication.

Print adhesion

Surface energy treated for optimal ink wetting. Compatible with UV, eco-solvent, and latex inks.

Opacity

White base provides >85% opacity. Prevents show-through and ensures color accuracy.

Processing flexibility

Cuttable with rotary or flatbed cutters. Drills and routs cleanly without delamination.

Surface texture

Gloss and matte options

The rigid printable film is available in gloss, semi-gloss, and matte finishes to suit different visual requirements. The gloss finish enhances color depth and contrast, ideal for high-impact signage. The matte finish reduces glare under overhead lighting, suitable for display panels in retail environments. The semi-gloss offers a balanced appearance for general applications. All finishes maintain consistent print quality and adhesion.

Technical specifications

Thickness0.30 – 0.80 mm

Width1.22 / 1.37 / 1.52 m

Opacity≥ 85%

Surface energy≥ 38 dynes/cm

Density1.38 – 1.42 g/cm³

Fire ratingB1 (GB 8624)

Temperature range-10°C to +50°C

Application scenarios

SignageIndoor wayfinding, promotional signs

DisplaysPOP, trade show graphics, shelf talkers

IndustrialEquipment labels, control panels

ArchitecturalWall panels, decorative cladding

PackagingPremium boxes, display cases

ⓘ

Handling recommendations

Store flat or rolled with core support. Allow 24-hour acclimation at 20-25°C before printing. Use sharp blades for cutting to prevent edge burrs. Lamination recommended for outdoor applications.

Frequently asked questions

Can this film be used for outdoor applications?

Short-term outdoor use (up to 6 months) is possible with UV-resistant inks and lamination. For permanent outdoor installation, an exterior-grade version with enhanced UV stabilizers is recommended.

What is the difference between rigid and flexible PVC film?

Rigid PVC film maintains its flat shape without curling, making it suitable for flatbed printing and flat applications. Flexible PVC bends and rolls, requiring tensioning for flat display. Rigid film is preferred for signage and panel applications where flatness is critical.

Can this be die-cut or routed?

Yes. The material accepts steel-rule die cutting, rotary cutting, and CNC routing. Use sharp tooling to achieve clean edges without chipping or delamination. Routing speed should be adjusted based on thickness.

What is the recommended ink type?

UV-curable inks provide the best adhesion and durability. Eco-solvent and latex inks are also compatible. Solvent-based inks require primer application for optimal adhesion.

________________________________________

Comply with ROHS, REACH, ISO9001, ISO14001 and other standards.
