Technical Data Sheet

Properties	Units	Test method	Average value
Base Fabric Yarn	Denier		1000DX1300D
Base Fabric Density	Thread/inch	FZ/T01003	18x17
Finished Fabric Weight	Gram/m2	FZ/T01003	610±3%
Thickness	mm	FZ/T01003	0.52±3%
Tensile strength at MD	N/5cm	GB/T1040	2900
Tensile strength at CD	N/5cm	GB/T1040	2700
Tearing Strength at MD	N/5cm	GB/T16578	540
Tearing Strength at CD	N/5cm	GB/T16578	320
Peeling Strength	N/5cm	GB/T3917	90
Temperature range	℃		-50 ~ +70
Anti-fungal			Optional
Anti UV			Optional
Frame Retardant			B1,B2,M1,M2 NFPA-701,C 19

PVC material is flame retardant (flame retardant value above 40), high chemical resistance (resistant to concentrated hydrochloric acid, 90% sulfuric acid, 60% nitric acid and 20% sodium hydroxide), mechanical strength. And the advantages of good electrical insulation. With some chemical additives, making PVC material be of anti-UV, anti-mildew, anti-frost, anti-statistic, anti-bacterial, higher level frame retardant performance. And for health consideration, we can also make it meet RoHS, REACH, EN71-3 standards. With PVC material advantages mentioned above, PVC fabric came into being.99.9％ polyester base fabric as reinforce of PVC material, making the fabric be of high performance of physical property to apply many fields in our industry and daily life.

18oz 1000D1300D 18X17 Truck Cover PVC Coated Polyester is a high-performance covering material designed for heavy-duty trucks. Made of 18 ounces (oz) of PVC coated polyester fiber, the material has excellent durability, waterproofness and tear resistance. Its unique 1000D1300D weaving technology and 18X17 yarn density ensure the stability and strength of the material, providing all-round protection for truck cargo.

Specific parameters and features

Material: PVC coated polyester fiber, which combines the waterproof and wear resistance of PVC with the lightness and flexibility of polyester fiber.
Weight: 18 ounces (oz), ensuring sufficient coverage and durability without being too heavy.
Weaving technology: Using 1000D1300D weaving technology, the yarn density reaches 18X17, which greatly improves the strength and durability of the material.
Waterproofness: PVC coating provides excellent waterproof performance, which can effectively protect the cargo from moisture even in bad rainy days.
Tear resistance: High-strength polyester fiber and unique weaving technology make the material have excellent tear resistance, even in strong winds or bumpy road conditions can remain intact.
Durability: After special treatment, the material has excellent weather resistance and wear resistance, and can maintain stable performance during long-term use.
Lightness: Despite its excellent durability and strength, the material still maintains a light weight, which is easy to install and carry.
Color: A variety of color options are available according to customer needs to meet different scenarios and aesthetic needs.

Scope, scenarios and fields

Transportation industry: This material is ideal for truck transportation and can effectively protect goods from rain, dust and ultraviolet rays.
Construction industry: On construction sites, this material can be used as a temporary cover to protect construction materials and tools from bad weather.
Agricultural field: In agricultural production, this material can be used as a cover for greenhouses or crops to improve the growing environment of crops.
Outdoor activities: In outdoor activities such as camping and picnics, this material can be used as a tent or mat to provide participants with a comfortable and safe resting environment.
